ECturn
6
Product description
Basic structure and extension6.2
Drive6.2.1
Controller cover1
Motor2
Gearing3
Battery (optional)4
Power connection (in the side element)5
Power plug6
Spindle cover7
Controller with power pack8
Hood (optional)9
Height-adjustable guide rail (±2 mm)6.2.2


Slide block10
Rail11
End piece12
Lever13
