GEZE ECturn Mounting Instructions

ECturn
4
Safety
Safety instructions3.2
The prescribed mounting, maintenance and repair work must be performed by properly trained personnel à
authorised by GEZE.
The country-specic laws and regulations are to be observed during safety-related tests. à
GEZE shall not be liable for injuries or damage resulting from unauthorised modication of the system. à
GEZE shall not be liable if products from other manufacturers are used with GEZE equipment. à
Only original GEZE parts may be used for repair and maintenance work as well. à
The connection to the power supply must be made by a professional electrician. Perform the power connec- à
tion and safety earth conductor test in accordance with DIN VDE 0100-610.
Exception: If the ECturn swing door drive is connected to the mains voltage by the mounted power plug, the
connection does not have to be carried out by a qualied electrician.
Use a customer-accessible 10-A automatic circuit-breaker as the line-side disconnecting device. à
Observe the latest versions of guidelines, standards and country-specic regulations, in particular: à
ASR A1.7 “Doors and Gates” à
DIN 18650 "Building hardware - Powered pedestrian doors" à
VDE 0100; Part 610 "Erection of low-voltage installations" à
Accident-prevention regulations, especially BGV A1 "General regulations" and BGV A2 "Electrical systems à
and equipment"
VDE 0100-610 "Erection of low-voltage installations" à
Safety-conscious working3.3
Secure the workplace against unauthorized entry. à
Use only cables prescribed in the cable plan. Lay screening in accordance with the wiring diagram. à
Secure loose, internal drive cables with cable ties.
Before working on the electrical system: à
Disconnect the drive from the 230 V mains network and check to ensure that it is deenergised. à
Disconnect the controller from the 24 V battery. à
Note that the system will still be supplied with power, despite the fact that the power supply is à
disconnected, if an uninterruptible power supply (UPS) is used.
Always use insulated wire-end ferrules for wire cores. à
Attach safety labels to glass door leaves. à
Danger of injury by broken glass! à
Danger of injury by sharp edges in the drive! à
Inspection of the mounted system3.4
Safety analysis (danger analysis)
In accordance with Machine Directive 2006/42/EC and DIN 18650, a danger analysis must be performed and the
door system identied in accordance with CE Identication Directive 98/68/EEC before commissioning the door
system.
This includes:
Checking measures for security and prevention of crushing, impact, shearing or drawing-in spots. à
Checking the function of the safety and actuation sensors. à
Checking the protective conductor connection to all metal parts which can be touched. à
Additionally applicable documents3.5
Drawing No. Type
70107-9-0951 ECturn wiring diagram
70107-9-0962 ECturn cable plan
The diagrams are subject to change. Use only the most recent versions.
