Setting GS342 using a remote control (optional)GC 342 safety sensor
Output conguration
R2
R2
R1
R2
SIO
SIS
SIS
1 2 3 4
NO NC
SIO
R1
NO NC NC NO No power
SIS
R2
NC NO NC NO
No detec-
tion
Detection
NO = Normally open
NC = Normally closed
Immunity lter
DIP 2 = ON
1 2 3 4 5 6 7 8 9
low > > > > > > > high
à Increase to lter out external disturbances
à Longer response time from value 5
Uncovered zone
DIP 2 = ON
1 2 3 4 5 6 7 8 9
2 4 6 8 10 12 14 16 18 cm*
Increase uncovered zone for snow, dead leaves etc.
*) Measured in specic conditions and dependent on the
application and installation
