Gigabyte GA-Z77N-WIFI User Manual

Hardware Installation - 24 -
6) SATA3 0/1 (SATA 6Gb/s Connectors, Controlled by Intel Z77/H77 Chipset)
The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA
1.5Gb/s standard. Each SATA connector supports a single SATA device. The "SATA3 0" and "SATA3 1"
connectors support RAID 0 and RAID 1. RAID 5 and RAID 10 can be implemented on the two connectors
with the "SATA2 2/3" connector
(Note)
5HIHUWR&KDSWHU&RQ¿JXULQJ6$7$+DUG'ULYHVIRULQVWUXFWLRQV
RQFRQ¿JXULQJD5$,'DUUD\
Pin No. 'H¿QLWLRQ
1GND
2TXP
3TXN
4GND
5RXN
6RXP
7GND
7) SATA2 2/3 (SATA 3Gb/s Connectors, Controlled by Intel Z77/H77 Chipset)
The SATA connectors conform to SATA 3Gb/s standard and are compatible with SATA 1.5Gb/s standard.
Each SATA connector supports a single SATA device. The Intel Z77/H77 Chipset supports RAID 0, RAID 1,
5$,'DQG5$,'5HIHUWR&KDSWHU&RQ¿JXULQJ6$7$+DUG'ULYHVIRULQVWUXFWLRQVRQFRQ¿JXULQJ
a RAID array.
Pin No. 'H¿QLWLRQ
1GND
2TXP
3TXN
4GND
5RXN
6RXP
7GND
 $5$,'RU5$,'FRQ¿JXUDWLRQUHTXLUHVDWOHDVWWZRKDUGGULYHV,IPRUHWKDQWZRKDUGGULYHV
are to be used, the total number of hard drives must be an even number.
 $5$,'FRQ¿JXUDWLRQUHTXLUHVDWOHDVWWKUHHKDUGGULYHV7KHWRWDOQXPEHURIKDUGGULYHVGRHV
not have to be an even number.)
 $5$,'FRQ¿JXUDWLRQUHTXLUHVIRXUKDUGGULYHV
(Note) When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system
performance of the RAID set may vary depending on the devices being connected.
1
1
7
7
SATA3
0
1
1
1
7
7
SATA2
3
2

Gigabyte GA-Z77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI

Weight and Dimensions

Width	170 mm
