- 9 - Hardware Installation
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can become
damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's
manual and follow these procedures:
 Prior to installation, make sure the chassis is suitable for the motherboard.
 Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
 Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
 When connecting hardware components to the internal connectors on the motherboard, make
sure they are connected tightly and securely.
 When handling the motherboard, avoid touching any metal leads or connectors.
 It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,
NHHS\RXUKDQGVGU\DQG¿UVWWRXFKDPHWDOREMHFWWRHOLPLQDWHVWDWLFHOHFWULFLW\
 Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
 Before unplugging the power supply cable from the motherboard, make sure the power supply
has been turned off.
 Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
 Before using the product, please verify that all cables and power connectors of your hardware
components are connected.
 To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
 Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
 Do not place the computer system on an uneven surface.
 Do not place the computer system in a high-temperature environment.
 Turning on the computer power during the installation process can lead to damage to system
components as well as physical harm to the user.
 If you are uncertain about any installation steps or have a problem related to the use of the
SURGXFWSOHDVHFRQVXOWDFHUWL¿HGFRPSXWHUWHFKQLFLDQ
Chapter 1 Hardware Installation

Gigabyte GA-Z77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI

Weight and Dimensions

Width	170 mm
