Gigabyte GA-Z77N-WIFI User Manual

Unique Features - 60 -
B. Updating the BIOS
In the main menu of Q-Flash, use the keyboard or mouse to select an item to execute. When updating the
%,26FKRRVHWKHORFDWLRQZKHUHWKH%,26¿OHLVVDYHG7KHIROORZLQJSURFHGXUHDVVXPHVWKDW\RXVDYHWKH
%,26¿OHWRD86%ÀDVKGULYH
Step 1:
 ,QVHUWWKH86%ÀDVKGULYHFRQWDLQLQJWKH%,26¿OHLQWRWKHFRPSXWHU,QWKHPDLQPHQXRI4)ODVKVHOHFW
Update BIOS From Drive.
Step 2:
7KHSURFHVVRIWKHV\VWHPUHDGLQJWKH%,26¿OHIURPWKH86%ÀDVKGULYHLVGLVSOD\HGRQWKHVFUHHQ:KHQ
the message "Are you sure to update BIOS?" appears, select Yes to begin the BIOS update. The monitor will
display the update process.
Step 3:
When the update process is complete, select Reboot to reboot the system.
2. Select USB Flash Drive..
 6HOHFWWKH%,26XSGDWH¿OH
 The Save BIOS to DriveRSWLRQDOORZV\RXWRVDYHWKHFXUUHQW%,26¿OH
 4)ODVKRQO\VXSSRUWV86%ÀDVKGULYHRUKDUGGULYHVXVLQJ)$7¿OHV\VWHP
 ,IWKH%,26XSGDWH¿OHLVVDYHGWRDKDUGGULYHLQ5$,'$+&,PRGHRUDKDUGGULYHDWWDFKHGWR
an independent SATA controller, use the <End> key during the POST to access Q-Flash.
0DNHVXUHWKH%,26XSGDWHÀOHPDWFKHV\RXUPRWKHUERDUGPRGHO
 Do not turn off or restart the system when the system is reading/updating the BIOS.
 'RQRWUHPRYHWKH86%ÁDVKGULYHRUKDUGGULYHZKHQWKHV\VWHPLVXSGDWLQJWKH%,26
Q-Flash
BIOS update is completed.
Power off
Reboot
Q-Flash Utility v1.05
Model Name : Z77N-WIFI
BIOS Version : F1c
BIOS Date : 07/31/2012
Flash Type/Size : MXIC 25L6465E/6406E 8MB
Update BIOS From Drive
Save BIOS to Drive
Return to BIOS setup
Select Device
USB Flash Drive.

Gigabyte GA-Z77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI

Weight and Dimensions

Width	170 mm
