Gigabyte GA-Z77N-WIFI User Manual

- 77 - Unique Features
Using EasyTune Touch
Step 1:
Go to the main menu of the EasyTune Touch application
on your iPhone. Select Connection.
Step 2:
On the Connection page, select :LÀ. iPhone will begin
to search for the computer using the same network
connection. When the computer is displayed, select it.
Then return to the main menu of the EasyTune Touch
application. Now you are able to use the EasyTune
Touch functions to remotely control the target computer
via the iPhone or check hardware information.
Step 1:
Go to the main screen of the PictureView application.
In the photo gallery, select Connect.
Step 2:
On the Connection page, select :LÀ. iPhone will begin
to search for the computer using the same network
connection. When the computer is displayed, select it.
Then return to photo gallery.
Using PictureView

Gigabyte GA-Z77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI

Weight and Dimensions

Width	170 mm
