Gigabyte GA-Z77N-WIFI User Manual

Appendix - 88 -
Delete RAID Volume
To delete a RAID array, select Delete RAID Volume in MAIN MENU and press <Enter>. In the DELETE
VOLUME MENU section, use the up or down arrow key to select the array to be deleted and press <Delete>.
When prompted to confirm your selection (Figure 12), press <Y> to confirm or <N> to abort.
Figure 12
Intel(R) Rapid Storage Technology - Option ROM - 11.1.0.1413
Copyright(C) 2003-12 Intel Corporation. All Rights Reserved.
Deleting a volume will reset the disks to non-RAID.
WARNING: ALL DISK DATA WILL BE DELETED.
(This does not apply to Recovery volumes)
[KL]-Select [ESC]-Exit [DEL]-Delete Volume
[ HELP ]
[ DELETE VOLUME MENU ]
Name Level Drives Capacity Status Bootable
Volume0 RAID0(Stripe) 2 223.6GB Normal Yes
ALL DATA IN THE VOLUME WILL BE LOST!
(This does not apply to Recovery volumes)
Are you sure you want to delete "Volume0"? (Y/N) :
[ DELETE VOLUME VERIFICATION ]
Acceleration Options
This option allows you to view the status of your accelerated drive/volume (Figure 13) created using the Intel
IRST utility. In case you are unable to run the Intel IRST utility due to an application error or operating system
issue, you will need to remove acceleration or manually enable synchronization (Maximized mode only) using
this option in the RAID ROM utility.
Steps:
Select Acceleration Options in MAIN MENU and press <Enter>.
To remove the acceleration, select the accelerated drive/volume, press <R>, and press <Y> to confirm.
To synchronize data from the cache device to the accelerated drive/volume, press <S> and press <Y> to confirm.
Figure 13
Intel(R) Rapid Storage Technology - Option ROM - 11.1.0.1413
Copyright(C) 2003-12 Intel Corporation. All Rights Reserved.
Press 's' to synchronize data from the cache device to
the Accelerated Disk/Volume
Press 'r' to remove the Disk/Volume Acceleration
WARNING: IT IS RECOMMENDED THAT YOU PERFORM A SYNCHRONIZATION
BEFORE REMOVING ACCELERATION
[KL]-Select [ESC]- Previous Menu
[ HELP ]
[ ACCELERATION OPTIONS ]
Name Type Capacity Mode Status
DISK PORT 3 Non-RAID Disk 74.5GB Enhanced In Sync
