Technical data
Gigaset E370A / LUG UK-IE en / A31008-M2841-L101-1-7619 / appendix_technical-A.fm / 9/14/17
Technical data
Batteries
Handset operating times/charging times
The operating time of your Gigaset depends on the capacity of the battery, its age and the way it is used.
(All times are maximum possible times.)
Power consumption of the handset in the charging cradle
Base power consumption
General specifications
Techn ology : 2 x AAA NiMH
Voltage: 1.2 V
Capacity: 750 mAh
Standby time (hours) 320 / 190 *
Talktime (hours) 17
Operating time with 1.5 hours of calls per day (hours) 120 / 95*
Charging time in charging cradle (hours) 8
* No Radiation switched on/off, without display backlight in idle status
(Setting the display backlight
p. 51)
When charging: approx. 1.5 W
To maintain the charge status: approx. 0.5 W
Standby: approx. 0.65 W
During a call: approx. 0.75 W
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency range 1880-1900 MHz
Duplex mode Time division multiplexing, 10 ms frame length
Repetition frequency of the transmission
pul
se
100 Hz
Duration of the transmission pulse 370 μs
Channel grid 1728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW average power per channel, 250 mW pulse power
Range Up to 50 m indoors, up to 300 m outdoors
