GigE MotionBLITZ EoSens mini1 - 3.6 UserSets

3.6 UserSets
3.6.1 Overview
The User Set feature is used to preserve current frame settings, even if the
camera is switched off. The frame values that are stored are frame width,
height, offset X and offset Y. The saved frame settings can be restored later by
the user or if the camera gets reset by a power on/ off cycle.
Name Type Access
UserSetSelector Enum R/W
UserSetLoad Command W
UserSetSave Command W
UserSetDefaultSelector Enum R/W
3.6.2 Controls
UserSetSelector
This feature must be set to ‘UserSet1’ before saving the current frame size by
the feature UserSetSave. The User Set Default is reserved for internal use. It
cannot be used to save user settings!
Access Read / write
Interface IEnumeration
Unit --
Range Default, UserSet1
Invalidation --
Precondition --
Note No data can be saved if User Set Default is selected.
By default the frame size is set to its maximum.
Feature description
MikrotronGmbH / mini1 / CAMMC1370/71-RG / 2021 29 - 67
