SyncInMode
This feature defines how the sync in signal is used for image acquisition.
Access Read / write
Interface IEnum
Unit --
Range Timer, PWC (= Pulse Width Control)
Invalidation --
Precondition CameraState = Idle
3.13 ExtTrigger
3.13.1 Overview
If the camera is in circular recording mode capturing frames can be stopped
by a signal on the external trigger input pin of the camera. The external stop
trigger feature must be enabled in the camera before it can be used.
Instead of an external trigger signal the ImageBlitz feature of the camera can
be used to generate trigger pulses internally.
If more than one capture buffers (sequences) are defined for recording the
camera stops recording to the current buffer and starts recording to the next
buffer on each trigger pulse. If the camera is writing to the last buffer (or the
first, if just one buffer is defined) the next trigger pulse will stop recording to
the buffer and set the camera to idle state.
If the camera has entered the idle state recorded frames can be read out of the
camera for further processing.
Name Type Access
ExtTriggerPolarity Enum RW
ExtTriggerEnable Boolean RW
Feature description
MikrotronGmbH / mini1 / CAMMC1370/71-RG / 2021 52 - 67
