THE ADVANCED SWITCHING SYSTEM
THE GIGRIG G3 USER MANUAL
8. TECH SPECS
Physical size: 44cm x 13cm x 7.8cm / 17.3" x 5.1" x 3.07"
Screen size: Approximately 5 x 3.8cm / 1.96"x 1.5"
Weight: 2.4 kgs / 5.29 lbs
Power Requirements:
G3/Atom 9V DC (2.1mm centre neg) @ 850mA
We recommend the use of The GigRig GenX14 or Generator power supply supplied with G3/S/Atom
Input impedance 1M Ohm
Out 1 - Signal path with input and output amps OFF – True Bypass
Out 1 is earthed and must always be connected to ground.
Out 2 - Signal path with input and output amps OFF – Buffered and Isolated
Out 2 uses our own High Def Isolation and is phase reversible.
Input signal handling Maximum = 16.5V dBV peak to peak in true bypass.
Signal Bandwidth = 5Hz to 150KHz (Outs 1&2)
Pre Gain/Buffer and Post Gain Stereo VCA Controlled Output Amplifier/Buffer
Minimum gain -30dBu
Maximum Gain +8dBu
Bandwidth at 1V = 4Hz to 150KHz.
Buffer output impedance 100 Ohms
Noise. 4.7nV per root Hz – really quiet
This specification is subject to change without notice. Consult our Web site for amendments.
www.thegigrig.com
