• Use a specific extractor to remove the flywheel
Specific tooling
020162Y Flywheel extractor
• Remove the two studs of the revolutions sensor
to the coolant inlet pipe.
• Remove the coolant inlet duct
• Remove the two stator fixing screws
• Remove the stator with wiring and revolution
sensor
Locking torques (N*m)
Flywheel nut 40 to 44 N.m
Refitting the stator
- To refit, perform the removal procedures in the reverse direction.
Engine Runner Purejet
ENG - 16
