Refitting the flywheel cover
•
Fit the rubber seal on the flywheel con-
nector and around the inlet coolant
hose.
•
Keeping the flywheel connector rubber
clamp on the coolant inlet hose, refit
the flywheel cover paying attention in
inserting the strap in the groove.
•
Tighten the 4 studs, noting that the two
longer golden screws are inserted in
the 2 top holes and are also responsi-
ble for restraining the secondary air-
box.
Cylinder assy. and timing system
• Remove the flywheel cover using the 4 screws
shown in the figure.
Runner Purejet Engine
ENG - 17
