• Remove the coolant outlet union from the head
with the relevant O-ring, using the two screws, as
shown in the figure.
• Remove the head inside recirculation duct as
shown in the figure.
• Remove the head using the 4 screws as shown
in the figure.
Runner Purejet Engine
ENG - 19
