WindObserver 65 Page 48 Issue 4
Doc. No. 1390-PS-0039 June 2016
Dx- Diagnostic and Configuration Command (see also Section 10.6)
Each of these commands causes a response from the WindObserver 65.
Item
Command
code
Typical response
Type and serial No.
D1
*
12400001
(
where * = E (Unheated unit), F = (Heated
unit)
Softwa
re version
D2
6
.0
1
Unit configuration
D3
Current configuration:
A0 B3 C1 E1 F1 G0000 H2 J1 K1 L1 M2 NA O1 P1 T1
U1 V1 X1 Y1 Z1
Analogue ID
(if present)
D4
Analogue Active (if fitted) or No analogue fitted.
Anemometer
power supply
voltage
D5
+29.8
Inte
grity check
D6
See Para 10.6 Bench Tests
Ex - Full Duplex/Half Duplex Mode
Setting
Configuration code
Full duplex
E1
Half duplex
E2
Note: - Refer also to Para 8.3 Networking Configuration details.
Fx- Data and Parity Options
Setting
Configuration co
de
8 bits, no parity, 1 stop bit
F1
8 bits, even parity, 1 stop bit
F2
8 bits, odd parity, 1 stop bit
F3
Note: If changing to F2, using a terminal program then when in configuration mode Type
F2 and press Enter, close the terminal program and open a new one with F2 Even parity
settings, then type F and press Enter.
Gx to Gxxxx - Averaging (Digital Outputs only)
Setting
Configuration code
Averaging (Default)
G0000
Enter the required averaging period in seconds as a four-figure number between 0000 and
3600.
Hx - Heating (If fitted)
Heating is autonomous and requires no set-up once activated.
Setting
Configuration code
Disabled
H1
Activated
H2
