Jx - Analogue Power-up Tests
Setting
Configuration code
Disable analogue power
-
up tests on switch on
J0
En
able single analogue power
-
up test on Switch on
J1
Enable continual cycling of analogue power
-
up tests
J2
Disable continual cycling of analogue power
-
up tests
J3
Analogue Power up tests cycle: -
Analogue Output Voltage connections between 0v, 1.25v, 2.5v, 3.75v and 5v.
Analogue Output Current connections between 0mA, 5mA, 10mA, 15mA and 20mA
Kx – NMEA Settings
Setting
Configuration code
NMEA string “IIMWV”
K1
NMEA string “WIMWV”
K2
Lx - ASCII Message Terminator
Setting
Configuration code
CR LF
L1
L
F
L2
Mx to Mxx - Message Format
Output format
Configuration code
ASCII UV Continuous
M1
ASCII Polar Continuous
M2
ASCII UV Polled (tri
-
state) *
M3
ASCII Polar Polled (tri
-
state) *
M4
NMEA Continuous
M5
Binary Tunnel Continuous
M6
Binary UV Conti
nuous
M7
Binary Polar Continuous
M8
ASCII Tunnel Continuous
M12
ASCII Tunnel Polled (tri
-
state) *
M13
ASCII Polar Polled Averaged
M14
ASCII Polar Continuous Averaged
M15
* If units are to be networked, they MUST be given unique Unit Identifiers
Nx - Node Address
Item Options Command
Node Address
A… -(A to Z)
N<A>
If used in a multi-drop system then it is recommended that ID’s A to F and K, M, N and P
are not used, as these characters can be present in the data string.
