COUNTING INSTANCE: WITH KNOWN THE SAMPLE’S QUANTITY AND THE UNIT WEIGHT
KEY (ORDER) STEP EXPLANATION LCD SCREEN DISPLAY
MENU LEVEL
AND CODE
Press and Hold
[MENU] Key
1. Enter Into Menu
--node-
1 .
Short Press [CAL] Key 2. Display counting Mode
-COUNT-
1 .1 .
Short Press [CAL] Key 3. Enter into Counting Program
SANPLE
1 .1 .1
Short Press [MENU]
key
4. Display Setting Menu
INPUT
1 .1 .2
Short Press [CAL] Key
5. Flash Sample Quantity (Example: 20pcs)
• Press [PRINT] key to cycle the sample quantity
setting O User can set sample quantity manually.
• Press [UNIT] key to move the cursor and press
[PRINT] key to increase the number.
0000020 pcs
1 .1 .2 .1
Short Press [CAL] Key
6. Flash Sample Unit Weight
• User can set sample unit weight:
Press [UNIT] key to move the cursor and press
[PRINT] Key to increase the number.
0002.000 g
1 .1 .2 .2
Short Press [CAL] Key
7. The display will show the result
• Three position to display the result as:
Upper left display quantity, Upper right display unit
weight: 0.1g, Main window display total weight
0.000g
8. Put any unknown numbers of pieces on pan and will
display a count. (Example: 300pcs)
Three position to display the result as:
Upper left display quantity 300pcs, Upper right
display unit weight: 0.1g, Main window display total
weight 30.000g
Press and Hold [TARE]
Key
9. Exit the counting function.
Quick restart: exit the present counting and restart a new counting. Press and hold (MENU) key can restart the step 1, short press (CAL) to
enter into step 3.
NOTE: The grey color words explain the signal’s meaning which flash on the window..
