COMMUNICATION INTERFACES

The following interfaces can be used to connect panels or repeaters to a Chameleon Network.

INTERFACE FOR RS422

COMMUNICATION

INT RS422 P2P-D

INT RS422 P2P-S

FIBRE-OPTIC INTERFACE

INT FO P2P-D

INT FO P2P-S

INTERFACE FOR TCP/IP

COMMUNICATION

INT-TCP-P2P

MIXED INTERFACE

INT RS422 P2P/MIX FO

NOTE:



For further installation guidelines or specific details, please refer to interface manual and/or

Chameleon Communications Manual.

NOTE:



Throughout the manual, the red pin on the 5 way molex indicates which pin is nº1.
