Logging In
To enter programming mode you need to log in.
The Panel must be powered up and must have initialized itself i.e. NOT showing the hourglass symbol.
Press ENTER on the Keypad. You must now insert your Installer access code. See page related to Access Levels. You
have unlimited attempts but if code entry is not started within 10 seconds then the panel will revert back to its default screen.
While entering the code you are allowed up to 5 seconds between key presses.
Function Selection
The programming functions are arranged using a menu system.
To select a function or sub-menu use either
🔺
or ▼ and ENTER.
ESC takes you back a menu level.
When required use the ▶ to scroll through loops.
The top level menus are:
1 Review Historic Log
3 Zones - Disable & Assign
4 Sounders - Disable & Assign
5 Input/Output - Disable & Assign
6 Device Set-up
7 Monitor Device Counts & Test
8 General
Most functions operate in a consistent manner using the standard keys. The item that is being changed is usually highlighted
with a flashing cursor.
GETTING THE SYSTEM RUNNING
1. Ensure all connectors are firmly in place. Ensure that all connections are tight, with no stray strands of wire.
2. If a Loop Card has been added to the panel, please ensure that it’s securely fitted to the back of panel’s Main Board.
3. Power up the Panel.
4. Ensure that the Panel is in Installation Mode (SYSTEM ON LED flashing). If not, enter programming mode and select
function 8-4-1 Active/Installation Mode and place panel into Installation Mode.
5. Press SYSTEM RESET.
Communications Check
Confirm that all Repeaters and Panels are showing identical information (LEDs and LCD), and that you can see on menu
“8-5-2 Known Panels” all the network. Repeat this procedure in all system panels.
Panel Check
Press and hold LAMP TEST on the Panel.
All the LEDs should light, the LCD backlight should turn on and all pixels on the LCD should be black.
26
