OVERVIEW
INTRODUCTION
This document covers the installation and commissioning of a GEKKO fire alarm panel. This document is intended for use by
a competent, qualified, fire alarm installation engineer.
The GEKKO fire alarm system should be tailored to the building requirements. The complete system should be designed to
meet all applicable regulations. The installation must then be performed in accordance with the system design. This manual
not only clarifies the components and connections during installation, but will also assist in commissioning and maintenance.
This manual covers the installation and commissioning of a complete system, excluding the communications system. Please
refer to Chameleon Communications Manual.
ELECTRO-STATIC SENSITIVE DEVICES (ESD)
TAKE SUITABLE ESD PRECAUTIONS WHEN REMOVING OR
INSTALLING PRINTED CIRCUIT BOARDS.
All PCBs contain Electrostatic Sensitive Devices.
Take suitable ESD (Electrostatic Discharge) precautions when removing or installing printed circuit boards (PCBs).
KEY FEATURES
● 1 to 4 loops panel
● Supports connection to Repeaters via RS422, Fibre-Optic or TCP/IP
● Networkable panel, compatible with OCTO+ and NODE+ range of panels
● Up to 250 devices per loop (only 125 addresses available )
● Up to 95 VULCAN 2 (addressable) ultra low current base sounders (32 address limit)
● 32 individually programmable sounder addresses
● Full Self-Addressable Devices support
● 2 Fire output relays (change-over) and 1 Fault relay (NC - opens on fault)
● 2 conventional alarm outputs (Individually programmable)
● Both detection loops monitored for integrity
● 384 fully programmable zones
● 512 fully programmable sounder groups
● 512 I/O groups
● Event log (rolling, 10000 entries)
● Available only with ZEOS protocol
● Compatible with all our own low cost ancillary modules
● Backlit graphical LCD display of 240x64 pixels
● Programming by integrated keypad or Loader PC software
● Multiple language support (menu selectable)
● Integrated 16 zone LED fire zone indication
3
