PROGRAMING FUNCTIONS DESCRIPTION
1 Review Historic Log
All the functions associated with reviewing or printing events and settings.
1-1 Display Historic Log
The panel logs all events in an internal event log. It can store a rolling 10000 entries. When it is full, the latest entry is added
and the oldest entry discarded.
Help is automatically displayed on entry to the function, because it is not possible to display a log entry and help at the
same time.
To select a specific entry, input the number and then press ENTER.
1-3 Clear Historic Log
Clears the Historic Log. Only if logged in with Master access code.
1-5 Read/Clear Autostart Count
Every time the Panel's power is cycled, the Autostart count is incremented. SYSTEM RESETs from the front panel button
do not increment the Autostart count.
3 Zones - Disable & Assign
All the functions associated with managing Zones
3-1 Disable Zones
Allows you to disable or enable Zones.
All devices in disabled Zones will cease to operate with the exception of the (audible) output from loop sounders.
Any Zones that are disabled will also be indicated when programming mode is exited. They can then be reviewed using
the DISABLED (QUEUE REVIEW) button.
3-2 Assign Sounder Groups to Zones
Sounder Groups (set up using the Sounders programming functions) can be assigned to Zones.
Each Zone can be assigned two sounder groups. The first Sounder Group is activated when the first fire is detected, the
second Sounder Group is activated when a second fire is detected in the same Zone.
3-3 Assign I/O Groups to Zones
I/O Groups (set up using the I/O programming functions) can be assigned to Zones.
The first 4 I/O groups are activated when the first fire is detected, the 5th I/O group is activated when a second fire is
detected in the same Zone.
The details of the activation are set up using the I/O programming functions.
3-4 Assign Zone to Device
Allows the detection Zone to be defined.
Select which devices make up which Zones. If a device has a text label, it will be displayed. If a Zone has a text label, it will
also be displayed.
Up to 384 Zones can be defined.
Zone 000 is not a Zone and indicates no Zone has been assigned.
3-5 Zone Sounder Delay Set-up
Allows the sounder activation delay to be enabled or disabled for each specific Zone.
Note that this delay will only occur if the following has also been set:
• Sounder programming function 4-6: The sounder delay period is set, the delay is set to ZONAL MODE and the devices
that initiate the delay have been specified.
• The front panel ACTIVE DELAYS button has been set to on (LED lit).
NOTE:
Specific devices in the Zone can be set to override this delay.
4 Sounders - Disable & Assign
4-1 Sounder Configuration
Allows selection of PRESET or PROGRAMMED sounder operation.
Selecting PRESET (the default) will result in all sounders being operated; any Sounder Group settings will be ignored.
33
