USER MANUAL
Range BEAT-Tr
Edition: January 2016
- MODE OF USE Revision: No. 3 30
C SEE FUSION RECORDS:
Validate the SEE FUSION RECORDS option to show the latest fusion stored in the memory.
00016 dd/mm/yy hh:mm
I AG d20 OK
Click the ª key to see the previous fusion.
Top line: fusion no.; date; start time.
Bottom line: fitting type (I = coupler in the example); brand (AG); diameter; result
(OK=correct; ERRn=incorrect > for the errors list, see CHAPTER 4: TROUBLESHOOTING).
In the case of electrofusion with manual data entry, the display will show the following
information:
00016 dd/mm/yy hh:mm
40.0V 0020s ERR2
Click the ª key to see the previous fusion.
Top line: fusion No.; date; start time.
Bottom line: electrofusion voltage; cycle time (completed if fusion OK or remaining if it
shows an error); result (OK=correct; ERRn=incorrect > for the errors list, see CHAPTER
4: TROUBLESHOOTING).
Click <STOP> to exit this option.
C EXPORT:
Validating the EXPORT option the fusion records can be transferred to a computer or to
a memory stick (depending on the model or user needs). The language of the fusion
records file will correspond to the one selected in the unit in the time of export.
>EXPORT
PRINT
Click the START key to validate.
Click the ª key to pass to the following option.
PC-SERIAL OPTION
:
The unit must have been previously connected to a computer using the null modem
transmission cable. No specific PC software is required. It is done using Windows Hyper
Terminal.
Connection configuration (for the first time):
1. Open Windows Hyper Terminal (usually in Programs / Accessories / Communica-
tions).
2. Accept any possible previous screens until you reach Connection Description:
Name: e.g., BEAT
Icon: Choose one of the icons shown.
OK
3. Connect to screen
Connect using: Select COM1 or COM2 as appropriate.
OK
