USER MANUAL
Range BEAT-Tr
Edition: January 2016
Revision: No. 3
MODE OF USE - 31
4. COM1/COM2 Properties screen
Port configuration:
Bits per second: Select 38400
Data bits: Select 8
Parity: Select None
Stop bits: Select 1
Flow control: Select None
OK
5. Connection created. When exit it is asked Do You Wish To Save? YES.
Exporting to a PC:
1. Run the connection created in Hyper Terminal.
2. With the unit on the >EXPORT screen, click the START/VALIDATE key.
EXPORTING RECORDS...
00%
The display will show the percentage of the data
exported.
3. Select Transfer and Receive file... in the Hyper Terminal menu:
Move the received file to the following folder:
C:\.................... the one you want.
Use reception protocol: Select Xmodem.
Receive
4. Name of the received file will appear
File name: The name you want. We recommend using *.txt or *.csv
extensions.
OK
5. The file will be transferred. The BEAT-Tr display will show the progress %.
Click <STOP> to exit this option. Disconnect the transmission cable.
PENDRIVE-USB/A OPTION
:
Connect a pendrive (format FAT or FAT32) to the USB/A socket (the connection can be
made at any time; it is not necessary with the unit off).
1. With the unit on the >EXPORT screen, click the START/VALIDATE key.
EXPORTING RECORDS...
00%
The display will show the percentage of the data
exported.
2. The file will be transferred. The unit’s display will show the progress %.
3. This will create a file in the pendrive’s BEAT folder (absent the folder is created
implicitly). The file name is FUSxxx.txt, where xxx is the first available number
between 000 and 999 that determines a unique filename.
Click <STOP> to exit this option. Disconnect the memory stick.
