Control / Settings channel
The Control / Settings commands listed below are available on Channel 9 in every
DMX mode.
Channel
Command
DMX
range
Percent
%
Default
DMX
Fade
9
Control /
Settings
Idle
0
9
0.0
3.5
0
Snap
No function
10
11
3.9
4.3
IQ.Service connect
12
13
4.7
5.1
No function
14
19
5.5
7.5
Dimming curve Soft / Square, (3 sec.)
20
21
7.8
8.2
Dimming curve Linear, 3 sec.
22
23
8.6
9.0
Dimming curve S-curve, 3 sec.
24
25
9.4
9.8
No function
26
29
10.2
11.4
Display mode: Off (3 sec.)
30
31
11.8
12.2
Display mode: Auto (3 sec.)
32
33
12.5
12.9
Display mode: On (3 sec.)
34
35
13.3
13.7
No function
36
37
14.1
14.5
Display orientation: Auto (3 sec.)
38
39
14.9
15.3
Display orientation: Normal (3 sec.)
40
41
15.7
16.1
Display orientation: Inverted (3 sec.)
42
43
16.5
16.9
No function
44
45
17.3
17.6
No signal: Blackout (3 sec.)
46
47
18.0
18.4
No signal: Hold (3 sec.)
48
49
18.8
19.2
No signal: Play captured scene (3 sec.)
50
51
19.6
20.0
No signal: Capture current scene (3 sec.)
52
53
20.4
20.8
No function
54
55
21.2
21.6
Fan mode: Off (3 sec.)
56
57
22.0
22.4
Fan mode: Regulated (3 sec.)
58
59
22.7
23.1
Fan mode: High (3 sec.)
60
61
23.5
23.9
Fan mode: Medium (3 sec.)
62
63
24.3
24.7
Fan mode: Low (3 sec.)
64
65
25.1
25.5
No function
66
69
25.9
27.1
Pixel mirror: Off (3 sec.)
70
71
27.5
27.8
Pixel mirror: x-mirror (3 sec.)
72
73
28.2
28.6
Pixel mirror: y-mirror (3 sec.)
74
75
29.0
29.4
Pixel mirror: x-y-mirror (3 sec.)
76
77
29.8
30.2
Pixel rotation: off (3 sec.)
78
79
30.6
31.0
Pixel rotation: 60° (3 sec.)
80
81
31.4
31.8
Pixel rotation 120° (3 sec.)
82
83
32.2
32.5
Pixel rotation 180° (3 sec.)
84
85
32.9
33.3
Pixel rotation 240° (3 sec.)
86
87
33.7
34.1
Pixel rotation 300° (3 sec.)
88
89
34.5
34.9
No function
90
91
35.3
35.7
Position feedback: Off (3 sec.)
92
93
36.1
36.5
Position feedback: On (3 sec.)
94
95
36.9
37.3
No function
96
97
37.6
38.0
Tilt invert Off (3 sec.)
98
99
38.4
38.8
Tilt invert On (3 sec.)
100
101
39.2
39.6
Pan invert Off (3 sec.)
102
103
40.0
40.4
Pan invert On (3 sec.)
104
105
40.8
41.2
No function
106
129
41.6
50.6
Performance: Fast (3 sec.)
130
131
51.0
51.4
Performance: Normal (3 sec.)
132
133
51.8
52.2
Performance: Smooth (3 sec.)
134
135
52.5
52.9
No function
136
137
53.3
53.7
