1 Basic information
1.1 Intended use
The LC 100 cutting machine cuts cables, litz wires, shrink sleeves and similar profiles and
is particularly suitable for series production.
The LC 100 is exclusively intended for cutting cables, litz wires, shrink sleeves and similar
profiles up to 8 mm.
Please note that only finely stranded copper litz wires up to 10 mm
2
and solid copper cables
up to a maximum of 2.5 mm
2
may be used. Steel wires or similar may never be used, as
these would destroy the cutter.
Willful modifications to the LC 100 are prohibited for safety reasons.
The required length and number of wires is entered either directly in the LC 100 with the key-
pad or can be documented on the PC with the supplied software and loaded to the LC 100.
1.2 For your safety
WARNING: The LC 100 may only be used
– as intended and
– when in perfect working order regarding safe functioning.
WARNING: All persons responsible for commissioning, operating and maintenance of
the LC 100 must be appropriately qualified and have read this user manual. In particular,
they must be able to recognize dangers.
NOTE: Only use original replacement parts from Phoenix Contact.
WARNING: The front door is installed for the safety of the operator. It is prohibited in all
circumstances to modify, remove or by means of alterations bypass it.
The LC 100 may be operated only when the front door is closed.
Disconnect the mains plug before beginning maintenance work.
Make sure that there are no foreign objects inside the housing.
