Operating the LC 100
102786_en_01 GLW 2-4
English
2.4 Automatic cable cutting
The LC 100 cuts the amount entered automatically to a specified length. This is the default
mode and is active when the machine is switched on.
• Switch on the LC 100.
• Insert the cable as described (see page 2-3).
• To switch into this mode, press the "mode" button and then the "1" key.
Entering the parameters • Enter the length and number of cuts with the keys "0" to "9".
• You can overwrite the values or delete them with the "C" button.
• For entries in inches, decimal places can be used.
• Switch to the next line with the "enter" key.
Cutting the cable • Press the "start" button. The green LED lights up.
The cable is then cut automatically.
Pausing or stopping the
cable
• Cutting can be interrupted. To do this, press the "stop" button. The red "stop" LED
flashes.
• Press the "start" button to continue cutting.
• If you would like to stop cutting, press and hold the "stop" button for at least two sec-
onds. The To go display is set to "0000".
Cutting finished When the cutting is completed, the To go display reads "0000" and a checkmark is shown.
The length and number can be re-entered.
Changing modes • Press the "mode" button to switch back to mode selection.
