6.5.2.B OVERLOAD INDICATION
6.5.1.B TILT READING
If any of the DIAGNOSTIC DISPLAYS read out the message LL, the internal tilt sensors are detecting
a TILT situation.
Further movements are being disabled, with the exception of lower the platform.
Lower the platform directly when the LL message is given. Position the machine of firm level ground.
6.5.1.A TILT READING
If the red light lit’s up (left), the internal tilt sensors are detecting a TILT situation.
Further movements are being disabled, with the exception of lower the platform.
Lower the platform directly when the light lit’s up. Position the machine of firm level ground.
6.5.2.A OVERLOAD INDICATION
If the red light lit’s up (right), the platform is overloaded.
No function will operate. An Alarm will sound.
1. Push in the EMERGENCY STOP to the OFF position
2. Remove weight from the platform.
3. Pull out the EMERGENCY STOP to the ON position
Front side upper control box - type A
If any of the DIAGNOSTIC DISPLAYS read out the message OL, the platform is overloaded.
No function will operate. An Alarm will sound.
1. Push in the EMERGENCY STOP to the OFF position
2. Remove weight from the platform.
3. Pull out the EMERGENCY STOP to the ON position
