Technical Specifications
Video
Component Video Out (1)
(Progressive/Interlace Scan modes)
• Y: 1.0Vp-p 75
Ω
• Pb: 0.7Vp-p 75Ω
• Pr: 0.7Vp-p 75Ω
S-Video Out (1)
(Separate Y and C signal output connec-
tor)
• Y: 1.0Vp-p 75
Ω, sync
• C: 0.286Vp-p 75
Ω
Video Out (1)
• 1.0Vp-p 75Ω, sync, RCA jack x 1
RF Out (1)
• Channel 3-4
S-Video In (2)
(Separate Y and C signal output connec-
tor)
• Y: 1.0Vp-p 75
Ω, sync
• C: 0.286Vp-p 75
Ω
Video In (2)
• 1.0Vp-p 75Ω, sync, RCA jack x 1
RF In (1)
• Antenna or CATV Input, F-Connec-
tor, 75W
Audio
Analog Out (1)
• 1.85V(rms)/10kΩ,
RCA jack (L,R) x 1
Coaxial Digital Audio Out
•0.5Vp-p 75Ω; RCA jack x 1
Optical Digital Audio Out
• Optical fiber transmitter
Frequency Response
• 20Hz to 20kHz
Signal-to-noise Ratio
• >90dB
Total Harmonic Distortion
• Less than 0.05%
General
Power Requirements
• 100-240VAC, 60Hz
Power Consumption
•20W
Environment
• 32ºF to 104ºF (9%-90% humidity)
Video Standard
•NTSC
Unit Weight (approx.)
• 10 lbs (4.5 kg)
Unit Dimensions (approx.)
• 17” x 11.4” x 2.7” (430 x 290 x 68
mm) (w/h/d)
Specifications subject to change without notice.
