Godex GS220 User Guide

14
Code Types and Decode Rules
Bar code descriptions marked with an asterisk ( * ) define a feature that is a
factory default. Bar codes marked with a tilde ( ~ ) require the Multi-Code
configuration method.
2 of 5 Codes
³ 9 0 1 6 0 0
~ ITF Symbol Length Lock 1 – To specify a first
ITF symbol length lock, scan this bar code and
the appropriate code byte sequence located
on page 23.
³ 9 0 1 7 0 0
~ ITF Symbol Length Lock 2 – To specify a second
ITF symbol length lock, scan this bar code and the
appropriate code byte sequence located
on page 23.
³ 9 0 3 4 0 0
~ ITF Minimum Symbol Length – To specify a
minimum number of ITF characters to be decoded,
scan the appropriate code byte sequence located
on page 23.
Additional Decode Features
³ 9 0 1 8 0 0
~ Minimum Symbol Length – Single-line default
is 3.
Combine this code with the proper code bytes
(on page 23), to specify the minimum number
of characters in all non-UPC/EAN bar codes.
³ 9 0 1 9 0 0
~ Symbol Length Lock – Combine this code with
the proper code bytes, to lock the bar code’s
length into place.

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
