Godex GS220 User Guide

1
Introduction
Components
Item No. Description
1 Red Output Window (Laser Aperture)
2 Trigger
3
Pinhole for Cable Release (see page 3)
4 10-Pin RJ45, Female Socket
5 Beeper Hole
6
LED Indicator (see page 5)
Figure 1. Scanner Components
Maintenance
Smudges and dirt on the unit’s window can interfere with the unit’s performance.
If the window requires cleaning, use only a mild glass cleaner containing no
ammonia. When cleaning the window, spray the cleaner onto a lint free, non-
abrasive cleaning cloth then gently wipe the window clean.
If the unit’s housing requires cleaning, use a mild cleaning agent that does not
contain strong oxidizing chemicals. Strong cleaning agents may discolor or
damage the
unit’s exterior.

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
