Godex GS220 User Guide

3
Cable Installation and Removal
Installation
1. Insert the cable’s modular connector into the socket on the scanner.
2. Pull gently on the cable strain relief to ensure the cable is installed.
Figure 3.
Removal
Turn off power to the host system before removing the cable from the scanner.
1. Locate the small pinhole on the
front side of the scanner near the
end of the handle.
2. Bend an ordinary paper clip into the
shape shown.
3. Insert the paper clip (or other small
metallic pin) into the small pinhole.
There will be a faint ‘click’ when the
connector’s lock releases.
4. Pull gently on the cable’s strain
relief to remove the cable.
Figure 4.

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
