Godex GS220 User Guide

17
Prefixes/Suffixes
Scan the Enter Configuration Mode bar code before trying to set these features
(see the Multi-Code Method on page 12.)
User Configurable Prefixes, All Data
³ 9 0 3 5 0 0
~ Configurable Prefix Character #1 – A prefix ID
can be added and assigned for data transmission.
Use this code with a code byte sequence, on page
23, which represents the desired character.
³ 9 0 3 6 0 0
~ Configurable Prefix Character #2 – Assigns a
second configurable prefix character.
Standard Prefix Characters
³ 1 1 6 6 1 5
Enable STX Prefix – The scanner will transmit a
Start of TeXt (ASCII 02H) before each bar code.
³ 1 1 6 6 0 5
* Disable STX Prefix
Standard Suffix Characters
³ 1 1 6 6 1 3
* Enable CR Suffix – The scanner transmits a
carriage return after each bar code.
³ 1 1 6 6 0 3
Disable CR Suffix
³ 1 1 6 6 1 2
* Enable LF Suffix – The scanner transmits a line
feed after each bar code. Disabled when
keyboard wedge defaults are loaded.
³ 1 1 6 6 0 2
Disable LF Suffix

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
