Godex GS220 User Guide

18
³ 1 1 6 6 1 0
Enable Tab Suffix – The scanner will transmit a
TAB (ASCII 09H) after each bar code.
³ 1 1 6 6 0 0
* Disable Tab Suffix
³ 1 1 6 6 1 4
Enable ETX Suffix – The scanner will transmit
End of TeXt (ASCII 03H) after the bar code date.
³ 1 1 6 6 0 4
* Disable ETX Suffix
³ 1 1 6 6 1 6
Enable UPC Suffix ID – The scanner will
transmit a suffix after any UPC/EAN bar code.
The suffixes are A (UPC-A), E (UPC-E),
F (EAN-13) and F (EAN-8).
³ 1 1 6 6 0 6
* Disable UPC Suffix ID
³ 9 4 1 6 0 0
Enable NCR Suffix Character
User Configurable Suffixes, All Data
Note: Scan the Enter/Exit Configuration mode code before trying to set this
feature. Refer to Multi-Code Method on page 12.
³ 9 0 4 5 0 0
~ Configurable Suffix Character #1 – A suffix ID
can be added and assigned for data
transmission. Use this code with a 3 code byte
sequence, on page
23, which represents the
desired character.
³ 9 0 4 6 0 0
~ Configurable Suffix Character #2 – Assigns a
second configurable suffix character.

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
