Godex GS220 User Guide

iii
Table of Contents
Introduction ............................................................................................. 1
Components ..................................................................................................... 1
Maintenance
..................................................................................................... 1
Caution and Serial Number Labels
................................................................... 2
Cable Installation and Removal
........................................................................ 3
Scanner Operation
Audible Indicators ............................................................................................. 4
Visual Indicators
............................................................................................... 5
Failure Modes
................................................................................................... 6
Typical Depth of Field
....................................................................................... 6
Troubleshooting Guide ........................................................................... 7
Design Specifications
........................................................................... 10
Configuration Introduction
Bar Code Configuration Methods ................................................................... 12
Single-Code Method
.................................................................................... 12
Multi
-Code Method
...................................................................................... 12
Returning to Factory Defaults
......................................................................... 13
Code Types and Decode Rules
2 of 5 Codes ................................................................................................... 14
Additional Decode Features
........................................................................... 14
Supplements .......................................................................................... 15
Scanner Operation
Redundant Scans ........................................................................................... 16
Data Transmission Delays
.............................................................................. 16
Laser/Scan Modes
......................................................................................... 16
Prefixes/Suffixes
User Configurable Prefixes, All Data .............................................................. 17
Standard Prefix Characters
............................................................................ 17

Godex GS220 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	72 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
USB version	2.0
Standard interfaces	USB
Connectivity technology	Wired
Certification	CE, FCC, BSMI
Product color	Black, Orange
Housing material	-
Input voltage	5 V
Power consumption (standby)	0.675 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	110 mm
Width	70 mm
Height	153 mm
Weight	120 g
