C o mmunic a tio n Po rt Sp e c ific a tio ns
Pino ut De sc riptio n
RT800i USER MANUAL
USB Po rtPo we r Ja c k Se ria l Po rt Ethe rne t Po rt USB Ho st Pa ra lle l Po rt
USB Po rt
Se ria l Port
Ethe rne t Port
USB Ho st
Pa ra lle l Po rt
1
4
2 1
3 4
5 4 3 2 1
9 8 7 6
1 8
18 1
36 19
C o nne c to r Typ e : Typ e B
Pin NO . 1 2 3 4
NC D- D+ G ND
C o nne c to r Typ e : Typ e A
Pin NO . 1 2 3 4
VBUS D- D+ GND
Typ e : RJ45
Pin NO.12345678
TX+ TX- RX+ NC NC RX- NC NC
Typ e : C e ntro nic s Fe m a le
Pin NO.1 2 3 4 5 6 7 8 9 101112131415161718
BUZY SELEC T AC K FAULTN LPT PERR DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 LPT INTN STRO B SELIN AUTO NC
Pin NO.192021222324252627282930313233343536
G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND G ND 5V
De fa ult Se tting s : Ba ud ra te 9600, no p a rity, 8 d a ta b it, 1 sto p b it, XON/ XO FF
Pro to c a l a nd RTS/ C TS
RS232 Ho using (9-p in to 9-p in)
Pin NO.123456789
- RXD TXD DTR G ND DSR RTS C TS RI
+5V,
ma x 500mA
TXD RXD N/ C G ND RTS C TS RTS N/ C
Typ e
DB9 So c ke t
DB9 Plug
****Se ria l p o rt to ta l o utp ut c a n no t e xc e e d the ma ximum c urre nt o f 500mA
No te
