45
Touch Screen: Slide the screen from
the left to the right to make the mode
interface appears, click the “Receiver”
icon to enter receiver mode.
Five receiver groups: A, B, C, D, E
The wireless is turned on by default in receiver mode.
Touch Screen: Click the “MODE” icon to switch to TTL mode.
Touch Screen: Click the “MODE” icon to switch to M mode.
Receiver Mode
Group
TTL: TTL Auto Flash
M: Manual Flash
Touch Screen: Click the group icon to switch groups.
The details of which please refer to the section Wi-Off mode
→
TTL auto flash above.
The details of which please refer to the section Wi-Off mode
→
M: manual flash above.
The flash power adjustable from 1/256 to 1/1 or from 2.0 to 10 when
choosing M (flash) mode.
You can choose auto zoom mode or manual zoom mode (28mm-105mm).
The details of which please refer to the ZOOM section in the Wi-Off mode
above.
Touch Screen: The flash power is adjustable by clicking the – or + icon, or
quickly adjustable by pulling the progress bar.
Flash Power Settings
ZOOM: Setting the Flash Coverage
Buttons and Select Dial: Press the
power switch button to make the mode
interface appears, rotate the select dial
and press the set button to choose and
enter receiver mode.
Buttons and Select Dial: Rotate the select dial to choose the group icon,
then press the set button to enter group settings and rotate the select dial to
switch groups, nally press the set button again to exit.
Buttons and Select Dial: Rotate the select dial to choose the “MODE” icon,
then press the set button to enter MODE settings and rotate the select dial
to switch to TTL mode, nally press the set button again to exit.
Buttons and Select Dial: Rotate the select dial to choose the “MODE” icon,
then press the set button to enter MODE settings and rotate the select dial
to switch to M mode, nally press the set button again to exit.
Buttons and Select Dial: Rotate the select dial to choose the flash power
box, press the set button to enter flash power settings and rotate the select
dial to adjust, nally press the set button again to exit.
