CONDENSING UNIT SPECIFICATIONS
8
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSC130363* - GSC130603*
GSC130484* - GSC130604*
GSC130363A* GSC130363B* GSC130483A* GSC130483B* GSC130603A* GSC130603B*
Nominal Cooling Capacity, BTUH 36,000 36,000 48,000 48,000 60,000 57,000
Compressor
R.L. Amps 9.0 9.0 12.4 12.4 17.3 14.7
L.R. Amps 65.5 65.5 88.0 88.0 123.0 91.0
Condenser Fan Motor
Horsepower 1/6 1/6 1/4 1/4 1/6 1/4
F.L. Amps 1.5 1.1 1.6 1.5 1.1 1.5
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 7/8" 7/8" 1-1/8" 1-1/8" 1-1/8" 1-1/8"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D.
3/4"
3
3/4"
3
7/8"
4
7/8"
4
7/8"
4
7/8"
4
Refrigerant Charge 119 83 150 102 167 131
Power Supply 208/230-60-3 208/230-60-3 208/230-60-3 208/230-60-3 208/230-60-3 208/230-60-3
Minimum Circuit Ampacity
(1)
12.7 12.4 17.2 17 22.7 19.9
Maximum Overcurrent Device
(2)
20 20 20 20 40 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 198 214 207 207 242 242
GSC130484A* GSC130484B* GSC130604A* GSC130604B*
Nominal Cooling Capacity, BTUH 48,000 48,000 60,000 60,000
Compressor
R.L. Amps 5.8 5.8 6.7 7.1
L.R. Amps 44.0 44.0 49.5 50.0
Condenser Fan Motor
Horsepower 1/4 1/4 1/6 1/4
F.L. Amps 0.8 0.8 0.6 0.8
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 1-1/8" 1-1/8" 1-1/8" 1-1/8"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D.
7/8"
4
7/8"
4
7/8"
4
7/8"
4
Refrigerant Charge 150 102 167 131
Power Supply 460 460 460 460
Minimum Circuit Ampacity
(1 )
8.0 8.1 9.0 9.7
Maximum Overcurrent Device
(2)
15 15 15 15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 207 189 242 185
