CONDENSING UNIT SPECIFICATIONS
9
VSC130181A* - VSC130301B*
VSC130[18-60]1*
VSC130361A* - VSC130601A*
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
VSC130181A* VSC130181B* VSC130241A* VSC130301A* VSC130301B*
Nominal Cooling Capacity, BTUH 18,000 18,000 24,000 30,000 30,000
Compressor
R.L. Amps 6.78 6.78 7.7 9.7 9.7
L.R. Amps 40 40 40 49 49
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/6 1/6
F.L. Amps 1.5 1.1 1.5 1.5 1.1
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Connection Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Charge 82 67 83 106 87
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
9.98 9.6 11.2 13.6 13.2
Maximum Overcurrent Device
(2)
15 15 15 20 20
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 141 128 150 195 156
VSC130361A* VSC130361B* VSC130421A* VSC130481A* VSC130601A*
Nominal Cooling Capacity, BTUH 36,000 36,000 42,000 48,000 60,000
Compressor
R.L. Amps 12.2 12.2 14.7 16.9 25.0
L.R. Amps 73 73 77 86 148
Condenser Fan Motor
Horsepower 1/6 1/6 1/4 1/4 1/6
F.L. Amps 1.5 1.1 1.8 1.5 1.1
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 7/8" 7/8" 1-1/8" 1-1/8" 1-1/8"
Refrigerant Connection Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.
3/4"
3
3/4"
3
7/8"
4
7/8"
4
7/8"
4
Refrigerant Charge 119 83 135 145 167
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
16.8 16.4 20.2 22.7 32.3
Maximum Overcurrent Device
(2)
25 25 30 40 50
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 199 189 199 198 242
