Goodwe DNS Series User Manual

10 Technical Parameters
40
User Manual V1.0-2022-12-15
User Interface LED, LCD, WLAN+APP
Communication WiFi, RS485 or 4G or 2G or LAN (Optional)
Weight (kg) 13 13 13 13 13.5
Dimension (W×H×D mm) 354 × 433 × 147
Noise Emission (dB) < 25 < 25 < 25 < 25 < 50
Topology Non-isolated
Self-consumption at Night (W) <1
Ingress Protection Rating IP65
Anti-corrosion Class C4
DC Connector MC4
AC Connector Plug and play connector
Environmental Category 4K4H
Pollution Degree III
Overvoltage Category DC II / AC III
Protective Class I
The Decisive Voltage Class (DVC) PV: C AC: C Com: A
Active Anti-islanding Method AFDPF + AQDPF
*6
Country of Manufacture (For
Australia only)
China
Technical Data GW5KBD-NS GW6KBD-NS
Input
Max. Input Power (W)
*1
6500 7200
Max. Input Voltage (V) 600 600
MPPT Operating Voltage Range (V) 80 - 550 80 - 550
MPPT Voltage Range at Nominal Power (V) 200 - 550 240 - 550
Start-up Voltage (V) 80 80
Nominal Input Voltage (V) 360 360
Max. Input Current per MPPT (A) 13 13
Max. Short Circuit Current per MPPT (A) 16.3 16.3
Max. Backfeed Current to The Array (A) 0 0
Number of MPP Trackers 2 2
Number of Strings per MPPT 1 1
Output
Nominal Output Power (W)
*2*3
5000 6000

Goodwe DNS Series Specifications

General

Max. Efficiency	97.8%
MPPT Efficiency	99.9%
Cooling Method	Natural Convection
Protection Rating	IP65
Start Voltage	80 V
Nominal AC Voltage	230 V
THDi	<3%
Number of MPPTs	2
Output Voltage	230 V
Frequency	50 Hz / 60 Hz
Type	Grid-Tied Inverter
Rated Power Output	3000W, 3600W, 4200W, 5000W
Communication	RS485
Max. DC Input Power	4500W, 5400W, 6300W, 7500W
Max. DC Voltage	550V
MPPT Voltage Range	80-500V
Rated AC Output Power	3000W, 3600W, 4200W, 5000W
AC Voltage Range	180V - 280V
Power Factor	0.8 leading to 0.8 lagging
Operating Temperature Range	-25°C to 60°C
MPPT Range	80-500V
Model	DNS Series
