Goodwe DNS Series User Manual

01 Disclaimer
1
User Manual V1.0-2022-12-15
1 About This Manual
1.1 Applicable Model
1.2 Target Audience
This manual describes the product information, installation, electrical connection, commissioning,
troubleshooting, and maintenance. Read through this manual before installing and operating the
product. All the installers and users have to be familiar with the product features, functions, and
safety precautions. This manual is subject to update without notice. For more product details and
latest documents, visit https://en.goodwe.com.
This manual applies to trained and knowledgeable technical professionals. The technical
personnel has to be familiar with the product, local standards, and electric systems.
This manual applies to the listed inverters below (DNS or Inverter for short):
Model Nominal Output Power Nominal Output Voltage
GW2900D-NS 2.9kW 127V
GW3000D-NS 3kW
220/230/240V
GW3600D-NS 3.6kW
GW4200D-NS 4.2kW
GW5000D-NS 5kW
GW6000D-NS 6kW
GW3000T-DS 3kW
GW3600T-DS 3.6kW
GW4200T-DS 4.2kW
GW5000T-DS 5kW
GW6000T-DS 6kW
GW5KBD-NS 5kW
GW6KBD-NS 6kW

Goodwe DNS Series Specifications

General

Max. Efficiency	97.8%
MPPT Efficiency	99.9%
Cooling Method	Natural Convection
Protection Rating	IP65
Start Voltage	80 V
Nominal AC Voltage	230 V
THDi	<3%
Number of MPPTs	2
Output Voltage	230 V
Frequency	50 Hz / 60 Hz
Type	Grid-Tied Inverter
Rated Power Output	3000W, 3600W, 4200W, 5000W
Communication	RS485
Max. DC Input Power	4500W, 5400W, 6300W, 7500W
Max. DC Voltage	550V
MPPT Voltage Range	80-500V
Rated AC Output Power	3000W, 3600W, 4200W, 5000W
AC Voltage Range	180V - 280V
Power Factor	0.8 leading to 0.8 lagging
Operating Temperature Range	-25°C to 60°C
MPPT Range	80-500V
Model	DNS Series
