• TheACoutputcable,loadoutputcable,DC input cable, andbatterycable
areconnectedtotheequipmentinthesameway.TaketheACoutput
cableconnectionasanexampletoexplaintheconnectionstepsbelow.
• Makesurethefollowingcablesareconnectedcorrectlytoavoid
equipmentdamage.
1. Positiveandnegativeterminalsofthebatteryareconnectedcorrectly.
2. PositiveandnegativeterminalsofthePVstringareconnected
correctly.
3. ACcableL1,L2,L3areconnectedinthecorrectsequence.
4. DonotmixPEcableandNwire.
NOTE
1
2
3
120-150mm
L=L1+(1~2)mm
L1
M8
8-10N·m
