Goodwe GW2000-SS - 3.4.3 RS485 Communication

15
If using Multi-contact connectors for the PV array terminals,
install as follows.
Female side connector (PV+) Male side connector (PV-)
Connectors must be installed as a pair, and each cable stripped
and installed as shown below.
