35
4 System Operation
4.1 Operating Panel
Figure 4.1-1
4.2 Indicator Lights
Yellow
For Non-WIFI type
Light on indicates the inverter is electrified; light off means the
inverter is not electrified.
For WIFI type
Light flashes on 1sec off 1sec indicates the WIFI module
doesn’t connect to the WIFI network; Light on 2.5sec off
2.5sec indicates the WIFI module connect to the WIFI network
and cannot receive data from WebServer; Always on indicates
To Next Page
