Goodwe GW2000-SS - GW4000-SS, GW4600-SS Parameters

51
Table 5.2 GW4000-SS, GW4600-SS
Model Name GW4000-SS GW4600-SS
DC input data
Max. PV-generator power [W] 4600 5400
Max. DC Voltage [V] 580 580
MPPT voltage range [V]
125～550 125～550
Turn on DC Voltage [V] 125 125
Turn off DC Voltage [V] 90 90
Max. DC work current [A] 20 20
Max. PV array short current[A] 27 27
Number of DC connections 3 3
Number of MPP trackers 1 1
DC-connection MC IV or HC IV-connector
Turn on power [W] 5 5
Night Power [W] 0 0
Output data
Nominal AC power 4000W 4600W
Max. AC power 4400W 5100W
Max. output current[A]
22 25
Nominal output voltage range According to VDE-AR-N 4105, VDE0126-1-
1/A1, AS4777.2./3, RD1699, CEI0-21, G59/2
AC grid frequency According to VDE-AR-N 4105, VDE0126-1-
1/A1, AS4777.2./3, RD1699, CEI0-21, G59/2
