52
THD(AC output current) <2%
Power factor ～1(Nominal power)
AC Connector Single phase with clamps
Efficiency
Max. efficiency 97.8% 97.8%
Euro efficiency >97.4% >97.4%
MPPT adaptation efficiency >99.5% >99.5%
Safety equipment
DC reverse polarity protection Integrated (with diode)
Leakage current monitoring unit Integrated
AC short protection Integrated
DC switch -disconnector Option
Islanding protection AFD
Grid Monitoring According to VDE-AR-N 4105, VDE0126-1-
1/A1, AS4777.2./3, RD1699, CEI0-21, G59/2
Normative reference
EMC- compliant according to EN 61000-6-1, EN 61000-6-2, EN 61000-6-
3, EN 61000-6-4
Safety compliance According to IEC62109-1, AS3100
General data
Dimensions (WxHxD) [mm] 390*417*142
Net Weight [kg] 18
Housing For outdoor and indoor
