User Manual V1.3-2023-01-31 05 Installation
13
1. The mounting support shall be nonammable and reproof.
2. Make sure that the support surface is solid enough to bear the product weight load.
3. Do not install the product on the support with poor sound insulation to avoid the noise
generated by the working product, which may annoy the residents nearby.
Mounting Support Requirements
Installation Angle Requirements
• Install the inverter vertically or at a maximum back tilt of 15 degrees.
• Do not install the inverter upside down, forward tilt, back forward tilt, or horizontally.
The following tools are recommended when installing the equipment. Use other auxiliary tools
on site if necessary.
Installation Tool Requirements
0%~100%RH
IP65
ALT: ≤3000m
Goggles Safety shoes Safety gloves Dust mask
RJ45 crimping
tool
