Gorilla Playsets Chateau - Front Frame Assembly; Hex Bolt

SANDBOX BOARD
5/16" WASHER
OFFSET HOLES UP
UP
OFFSET HOLES
BOARD
TOP PANEL
2 X 4 X 70"
UP
OFFSET HOLES
BOARD
2 X 6 X 70"
FRONT FACE
2 X 6 X 70"
5/16 X 4-1/2"
HEX BOLT
STEP 5: FRONT FRAME ASSEMBLY
1: PLACE THE 2 X 6 X 70" SANDBOX BOARD ON THE FRONT OF THE CORNER POSTS. THE OFFSET HOLES IN THE
SANDBOX BOARD SHOULD FACE UP.
2: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE SANDBOX BOARD TO THE
T-NUTS INSTALLED ON THE CORNER POSTS. THE BOTTOM HOLES WILL BE USED LATER.
3: PLACE THE 2 X 6 X 70" FRONT FACE BOARD WITH NOTCHES ON THE FRONT OF THE CORNER POSTS. THE OFFSET
HOLES IN THE FRONT FACE BOARD SHOULD FACE UP.
4: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE FRONT FACE BOARD TO
THE T-NUTS INSTALLED ON THE CORNER POSTS. THE BOTTOM HOLES WILL BE USED LATER.
5: PLACE THE 2 X 4 X 70" TOP PANEL BOARD ON THE FRONT OF THE CORNER POSTS. THE OFFSET HOLES IN THE TOP
PANEL BOARD SHOULD FACE UP.
6: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE TOP PANEL BOARD TO
THE T-NUTS INSTALLED ON THE CORNER POSTS.
