Gorilla Playsets Chateau - STEP 16-17: LADDER ASSEMBLY AND ATTACHMENT

2" WOOD
SCREW
5/4 X 3 X 18-3/4"
LADDER BACK
LADDER SIDE
2 X 4 X 66"
T-NUT
OTHER AND ARE PARALLEL.
OF THE
STEP 16: LADDER
LADDER SIDES AND SET WITH A HAMMER.
3: INSERT T-NUTS INTO THE OUTSIDE
BOLTS, 5/16 WASHERS, INTO THE 5/16" T-NUTS.
INSIDE OF THE LADDER RAILS WITH 5/16 X 1-1/2"
ANGLE BRACKETS TO THE
5: PLACE THE STEPS INTO THE SLOTS ON THE
PUT THE SCREWS INTO THE OTHER SIDE.
LADDER SIDES, AND FASTEN WITH 2" WOOD
SCREWS.
6: CAREFULLY TURN THE LADDER OVER AND
1: FIND TWO 2 X 4 X 66" LADDER SIDES.
2: POSITION THE LADDER SIDES SO THAT THE
SLOTS IN THE BOARDS ARE FACING EACH
4: FIND FIVE 2 X 4 X 17" LADDER STEPS.
7: INSTALL THE 90
8: INSTALL THE 5/4 X 3 X 18-3/4" LADDER
BACK ABOVE THE TOP STEP OF THE LADDER
WITH TWO 2" WOOD SCREWS PER SIDE.
LADDER
STEP
2 X 4 X 17"
2" WOOD
SCREW
HEX BOLT
ANGLE
BRACKET
90
5/16 X 1-1/2"
5/16" WASHER
