STEP 6: REAR FRAME ASSEMBLY
1: PLACE THE 2 X 6 X 70" SANDBOX BOARD ON THE REAR OF THE CORNER POSTS. THE OFFSET HOLES IN THE
SANDBOX BOARD MUST FACE UP.
2: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE SANDBOX BOARD TO THE
T-NUTS INSTALLED ON THE CORNER POSTS. THE BOTTOM HOLES WILL BE USED LATER.
3: PLACE THE 2 X 6 X 70" BOTTOM PANEL BOARD ON THE FRONT OF THE CORNER POSTS. THE OFFSET HOLES IN
THE FRONT FACE BOARD MUST FACE UP.
4: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE BOTTOM PANEL BOARD
TO THE T-NUTS INSTALLED ON THE CORNER POSTS. THE BOTTOM HOLES WILL BE USED LATER.
5: PLACE THE 2 X 4 X 70" REAR TOP PANEL BOARD ON THE FRONT OF THE CORNER POSTS. THE OFFSET HOLES IN THE
TOP PANEL BOARD MUST FACE UP.
6: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE TOP PANEL BOARD TO
THE T-NUTS INSTALLED ON THE CORNER POSTS.
SANDBOX BOARD
5/16" WASHER
OFFSET HOLES UP
2 X 6 X 70"
BOTTOM PANEL BOARD
OFFSET HOLES UP
2 X 4 X 70"
REAR TOP PANEL BOARD
OFFSET HOLES UP
LAG SCREWS ARE
SELF-TAPPING.
HOLES IN THE
CORNER POSTS FOR
THE LAG SCREWS.
7: PLACE THE FRAME
IN ITS FINAL POSITION
AND FOLLOW THE
PROCEDURES AT THE
FRONT OF THE
MANUAL ON PAGE 10
TO LEVEL AND
SQUARE THE
STRUCTURE. ONCE
THE FRAME IS LEVEL,
SQUARE, AND SET
INTO POSITION; GO
BACK AND INSERT THE
5/16 X 3-1/2" LAG
SCREWS AND 5/16"
WASHERS IN ALL OF
THE REMAINING
HOLES OF THE 2 X 6
PARTS. NOTE: THERE
WILL NOT BE ANY
PREDRILLED
2 X 6 X 70"5/16 X 4-1/2"
HEX BOLT
